Bim modeling is the translation of documentation from 2D to 3D

Our BIM Architectural Modeling services focus on developing Revit Architectural models for each building design phase – Schematics Design (SD), Design Development (DD), Construction Document (CD) as per the design intent.

The services also include developing Custom Revit Family or BIM Content, BIM Drafting models from Point Cloud Data/PDF/2D AutoCAD, and clash detection & resolution i.e. develop the construction-ready model by coordinating architectural models with other disciplines – Structural & MEPFS.

Also we create mechanical, electrical,
and plumbing Revit models as per
the design-intent and as required for
each design phase – schematic design,
design document and construction document.

THREE WAYS OF WORKING

Loading BIM templates based on the
client’s standards for each
of the listed trades
Creating of a product
specification sheet + template
Revisions
Coordination Space Model
for Assemblability
Document analysis
Reviewing
and Resolving Clashes
Project Approval
Signing the Project
Completion Certificate

We can provide the MODELING in the following file format:

.RVT
.NWD

We load the data into the program. We create the geometry, write the parameters, bring in specifications, grades. In addition, we’ll do clash detection and mismatch removal.
